🔧 Introduction: DIY Smart Upgrade for Your Geyser
Want to control your geyser from your phone and save on electricity in Pakistan’s rising utility rates? The Home Genius Smart Electric Geyser Switch makes it easy to schedule, monitor, and remotely control your geyser using the eWeLink app.
This blog will walk you through the step-by-step installation, wiring, app pairing, and common setup issues based on our official wiring diagram, user manual, and video tutorial.
🧰 What’s in the Box?
- 1x Smart Geyser Switch (16A or 20A)
- 1x Transparent Waterproof Protective Cover
- 1x Instruction Manual (PDF available here)
- Mounting screws & plate
🧠 Smart Features at a Glance
✅ App control via eWeLink
✅ Schedule geyser ON/OFF times
✅ Voice assistant compatible (Alexa, Google)
✅ Power consumption monitoring (kWh)
✅ Overload, short-circuit, and over-temperature protection
✅ Works with both electric & electric/gas hybrid geysers
🔌 Wiring Diagram (Electric Geyser Setup)
Below is the actual wiring layout you should follow:
Terminal Definitions
- L In = Live input from your power line
- N In = Neutral input
- L Out = Load output to geyser (Live)
- N Out = Neutral to geyser
📌 Ensure the geyser power rating matches the switch limit (16A or 20A).
🎥 Installation Video Tutorial
Watch our full video guide:
👉 Installation & Configuration – Smart Geyser Switch (Video)
⚠️ Safety Tips Before You Begin
- Turn off your main power supply at the circuit breaker.
- Use an electric tester to confirm no current.
- If unsure, contact an electrician to assist.
🔧 Step-by-Step Installation (Pakistan Use Case)
Step 1: Open the Existing Geyser Switch
Unscrew your wall switch panel. Identify Live (L) and Neutral (N) wires from both the mains and geyser.
Step 2: Match Wiring as Per Diagram
Connect the wires to the correct terminals on the smart switch. Double-check against the wiring diagram above.
Step 3: Mount in Waterproof Casing
Install the switch inside the transparent cover to protect it from water, humidity, and dust.
Step 4: Turn Power Back On
Switch on the circuit breaker and confirm that the device powers up.
📲 App Setup: Pairing with eWeLink
Step-by-Step:
- Download eWeLink from Play Store / App Store
- Tap “+ Add Device”
- Put the switch in pairing mode (hold power button 5–7 seconds until LED blinks)
- Enter WiFi credentials (only 2.4GHz supported)
- Name your switch “Geyser” and tap Done
You can now:
- Schedule routines
- Set countdown timers
- Monitor energy use
- Control via voice assistant
🛠️ Common Problems & Solutions
Issue: Device not connecting to WiFi?
- Make sure your WiFi is 2.4GHz only.
- Turn off 5GHz band temporarily if router merges both.
- Reboot your router and try pairing again.
Issue: App shows “Offline” even though power is on
- Weak WiFi signal near the switch. Use a repeater or move the router closer.
More troubleshooting is available in our official guide:
📄 Common Problems in Setting Up SEGS (PDF)
🏠 Why Pakistan Homes Need This
- Prevent accidental overuse during load-shedding recovery
- Schedule geyser before Fajr or after office hours
- Save up to 70% electricity monthly
✅ Final Thoughts
You don’t need to be an electrician to enjoy the convenience of a smart geyser. In just 20–30 minutes, your geyser becomes voice-activated, scheduled, and remotely controllable — all via the Home Genius Smart Switch and the eWeLink app.
